HARDWARE FEATURES
Interface PCI Express
Dimensions 4.8 × 3.3 × 0.85 in (120.8 × 83.2 × 21.5 mm)
Antenna 2 Detachable External Antennas
BLUETOOTH FEATURES
Standards and Protocols Bluetooth 4.2, Bluetooth 4.0
Interface USB 2.0
WIRELESS FEATURES
Wireless Standards IEEE 802.11b/g/n 2.4 GHz, IEEE 802.11a/n/ac 5 GHz
Signal Rate 11ac: Up to 867 Mbps(dynamic)
11n: Up to 300 Mbps(dynamic)
11a: Up to 54 Mbps(dynamic)
2.4 GHz:
11n: Up to 300 Mbps(dynamic)
11g: Up to 54 Mbps(dynamic)
11b: Up to 11 Mbps(dynamic)
Reception Sensitivity 5 GHz:
11ac HT80: -59.0dBm
11n HT40: -68.5dBm
11a 54Mbps: -73.5dBm
11a 6Mbps: -91dBm
2.4 GHz:
11n HT40: -69.5dBm
11g 54Mbps: -74dBm
11b 11Mbps: -87dBm
Transmit Power 5 GHz: 21.5dBm(FCC)
2.4 GHz : 20.5dBm(FCC)
Wireless Modes Infrastructure mode
Wireless Security WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM
