    TP-Link TL-POE150S PoE Injector 12/9/5VDC output

    Manufacturer: Tp-Link
    The PoE Injector TL-POE150S fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PDs (Powered Devices) or PoE Receiver Adapters, such as TP-LINK’s TL-POE10R, or other equivalent product, to expand your network to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc.
    SKU: NWI0001
    Manufacturer part number: TL-POE150S
    Availability: 24 in stock
    €19.90 incl VAT
    i h

    HARDWARE FEATURES
    Interface 2 10/100/1000Mbps RJ45 Port
    AUTO Negotiation/AUTO MDI/MDIX
    1 48VDC POWER INPUT PORT
    Network Media 10BASE-T: UTP category 3, 4, 5 cable (Max 100m)
    EIA/TIA-568 100Ω STP (Max 100m)
    100BASE-TX: UTP category 5, 5e cable (Max 100m)
    EIA/TIA-568 100Ω STP (Max 100m)
    1000BASE-T: UTP category 5, 5e, 6 cable (Max 100m)
    Dimensions (W X D X H) 3.2*2.1*0.9 in.(80.8*54*24 mm)
    Power Supply 15.4W (Max. 48VDC)
    LED Indicator PWR

    SOFTWARE FEATURES
    Basic Function Compatible With IEEE 802.3af Compliant PDs
    Delivers Power Up To 100 Meters
    Auto-Determine The Necessary Power Requirements

    OTHERS
    Certification FCC, CE, RoHS
    System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
    Environment Operating Temperature: 0?~40? (32?~104?)
    Storage Temperature: -40?~70? (-40?~158?)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~90% non-condensing
