| GENERAL FEATURES |
| Type | Line-Interactive (VI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Rack |
| Rack Units [U] | 2U |
| Power Capacity | 1000VA / 900W |
| Output Power Factor | 0.90 |
| INPUT |
| Input Voltage Range | Acceptable Voltage Range: 176-288VAC
Line Low Transfer (Wide Mode): 154/161/168VAC ± 4%
Line Low Transfer: 176/184/192VAC ± 4%
Line Low Comeback: 186/194/202VAC ± 4%
Line High Transfer: 264/276/288VAC ± 4%
Line High Comeback: 254/266/278VAC ± 4% |
| Frequency Range | 45Hz – 65Hz (self-adaptive to 50/60Hz); 40Hz – 65Hz for generator mode |
| OUTPUT |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 220/230/240 VAC |
| Voltage Regulation (Battery Mode) | ±5% |
| Frequency (Battery Mode) | ±0.1Hz |
| INPUT & OUTPUT CONNECTORS |
| Input Connector | C14-UK |
| Output Type | IEC – UK |
| IEC C13 | 4 |
| TECHNICAL DETAILS |
| LINE Mode Efficiency [%] (Full Load) | 97.8 |
| Battery Mode Efficiency [%] (Full Load) | 85.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 2-6ms typical |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 2-6ms typical (10ms max | 13ms for Generator Mode) |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | <10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 2-6ms typical |
| Load Crest Ratio | 3:1 |
| Data Line Protection | RJ-11 Port, RJ-45 Port (100mbit) |
| Additional Features | OBM – Optimized Battery Management, LCD Display, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VI-SS-311 |
| BATTERIES AND AUTONOMY |
| Batteries | 2x 12.0V/9.0Ah |
| DC Voltage | 2x 12.0V |
| Recharge Time | 8h to 90% |
| Full Load Backup Time [min] | 3.0 |
| Half Load Backup Time [min] | 10.0 |
| Charger | 1.1A |
| COMMUNICATION |
| Communication | USB Type B – for Monitoring Software, RS-232 |
| Software | WinPower |
| ENVIRONMENT |
| Noise Level | < 45dB |
| Fan Logic | Fan Off: Line/ Standby Mode and Load below 80% Always On, Automatic Fan Control (AVR On, Battery Mode and Battery Charging) |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 80% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS |
| Package Content | UPS, Manual, USB Cable, Tower Holder, Rack Ears, 2x IEC Cable, EPO Plug, Input Power Cable |
| Manual Languages | DE, RU, PL, FR, HU, CZ, EN |
| EAN | 4260074976205 |
| Product Dimensions (DxWxH) [mm] | 436 x 438 x 86 mm |
| Product Weight [kg] | 13.8 |
| Package Dimensions (DxWxH) [mm] | 545 x 545 x 230 mm |
| Package Weight [kg] | 15.8 |
| Pcs. per Outer Carton | 1 |
