GENERAL FEATURES |
Type | Online Single Phase (VFI) |
Phases (IN-OUT) | 1-1 |
Form Factor | Tower |
Power Capacity | 6000VA / 6000W |
Output Power Factor | 1.00 |
INPUT |
Input Voltage Range | 160-276 VAC at 100% load 110-160VAC range linear between 50-100% load |
Frequency Range | 40Hz – 70Hz (self-adaptive to 50/60Hz) |
Frequency (Synchronized Range) | 45Hz – 55Hz at 50Hz nominal 54Hz – 66Hz at 60Hz nominal and >60% rated load |
OUTPUT |
Waveform | Pure Sine Wave |
Nominal Output Voltage | 208/220/230/240 VAC |
THDv | ≤1% @ 100% linear load, ≤5% @ 100% non-linear load |
Voltage Regulation (Battery Mode) | ±1% |
Frequency (Battery Mode) | ±0.1Hz |
INPUT & OUTPUT CONNECTORS |
Input Connector | Terminal |
Output Type | Terminal |
Terminal Output | Yes |
TECHNICAL DETAILS |
LINE Mode Efficiency [%] (Full Load) | 95.0 |
Battery Mode Efficiency [%] (Full Load) | 93.0 |
Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 10ms |
Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 0ms |
Load Crest Ratio | 3:1 |
Bypass | Manual – Bypass |
Additional Features | Earthing System Available, ECO Mode Available, CVCF Mode Available, Potential Equalization Screw, Parallel Connectivity, LCD Display, Unity Power Factor 1.0, Input Breaker, Battery Pack Available, Generator Compatible, EPO – Emergency Power Off, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
IEC 62040-3 classification | VFI-SS-111 |
BATTERIES AND AUTONOMY |
Batteries | 16x 12.0V/7.0Ah |
DC Voltage | 16x 12.0V |
Recharge Time | 3h to 90% |
Full Load Backup Time [min] | 4.0 |
Half Load Backup Time [min] | 11.0 |
Charger | 0-4A [1.4A] |
External Battery Pack | Yes |
COMMUNICATION |
Communication | Dry contact, USB Type B – for Monitoring Software, RS-232, Management Card Slot |
Software | WinPower |
Parallel Operation [Units] | 3 |
ENVIRONMENT |
Noise Level | < 50dB |
Fan Logic | Always on, Automatic Speed Control |
Temperature | 0°C – 40°C (40°C – 50°C @50% load) |
Humidity | 0% – 95% RH (non-condensing) |
IP | IP 20 |
LOGISTICS |
Package Content | Manual, USB Cable, Protective Plates and screws for parallel port, Dry Contact Plug, Parallel Communication Cable, UPS |
Manual Languages | EN |
EAN | 4260074980110 |
Product Dimensions (DxWxH) [mm] | 452 x 225 x 589 mm |
Product Weight [kg] | 52.7 |
Package Dimensions (DxWxH) [mm] | 598 x 397 x 730 mm |
Package Weight [kg] | 55.6 |
Pcs. per Outer Carton | 1 |
