Type | Online Three Phase (VFI) |
Phases (IN-OUT) | 3-3 |
Form Factor | Tower |
Power Capacity | 30000VA / 30000W |
Output Power Factor | 1.00 |
INPUT |
Input Voltage Range | 305-478 VAC (3-phase) @100% load 190-520 VAC (3-phase) @50% load |
Max THDi | ≤4% Full Linear Load; ≤6% Half Load |
Frequency Range | 46Hz – 54Hz or 56Hz – 64Hz |
Frequency (Synchronized Range) | 46Hz – 54Hz or 56Hz – 64Hz |
OUTPUT |
Waveform | Pure Sine Wave |
Nominal Output Voltage | 3x 400V (3Ph+N); (208)/220/230/240VAC(Ph-N) |
THDv | ≤2% @ 100% linear load, ≤4% @ 100% non-linear load |
Voltage Regulation (Battery Mode) | ±1% |
Frequency (Battery Mode) | ±0.1Hz |
INPUT & OUTPUT CONNECTORS |
Input Connector | Terminal |
Terminal Output | Yes |
TECHNICAL DETAILS |
LINE Mode Efficiency [%] (Full Load) | 95.5 |
Battery Mode Efficiency [%] (Full Load) | 94.5 |
Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | <10ms |
Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | <10ms |
Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 0ms typical (4ms max) |
Load Crest Ratio | 3:1 (max) |
Bypass | Manual – Bypass |
Additional Features | Battery Pack Available, Dual Input Option, ECO Mode Available, EPO – Emergency Power Off, Generator Compatible, HID – Human Interface Device, Input Breaker, Parallel Connectivity, Touch-Display, Unity Power Factor 1.0, External Battery Compatible, Battery-Sharing |
IEC 62040-3 classification | VFI-SS-111 |
BATTERIES AND AUTONOMY |
Batteries | 2.0x32x 12.0V/7.0Ah |
DC Voltage | 32x 12.0V |
Adjustable Batteries in String | 32-40 |
Recharge Time | 9h to 90% |
Full Load Backup Time [min] | 2.5 |
Half Load Backup Time [min] | 7.2 |
Charger | 1-12A |
External Battery Pack | Yes |
COMMUNICATION |
Communication | Dry contact, USB Type B – for Monitoring Software, RS-232, Management Card Slot |
Software | ViewPower |
Parallel Operation [Units] | 3 |
ENVIRONMENT |
Noise Level | < 65dB |
Fan Logic | Always on, automatic speed control |
Temperature | 0°C – 40°C |
Humidity | 0% – 95% RH (non-condensing) |
IP | IP 20 |
LOGISTICS |
Package Content | Manual, UPS |
EAN | 4260074981353 |
Product Dimensions (DxWxH) [mm] | 815 x 300 x 1000 mm |
Product Weight [kg] | 225.0 |
Package Weight [kg] | 237.0 |
Pcs. per Outer Carton | 1 |
