| GENERAL FEATURES |
| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Tower |
| Power Capacity | 3000VA / 2700W |
| Output Power Factor | 0.90 |
| INPUT |
| Input Voltage Range | 80-300V @ 0-50% load
140-300V @ 50-60%
160-300V @ 60-80%
190-300V @ 80-100% |
| Frequency Range | 40Hz – 70Hz |
| Frequency (Synchronized Range) | Adjustable 1-10% (default ±8%)
Outside of the range, it switches to converter mode |
| OUTPUT |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 208/220/230/240 VAC |
| THDv | ≤3% @ 100% linear load, ≤5% @ 100% non-linear load |
| Voltage Regulation (Battery Mode) | ±1% |
| Frequency (Battery Mode) | ±0.5Hz |
| INPUT & OUTPUT CONNECTORS |
| Input Connector | C20-UK |
| Output Type | Type G |
| Type G (BS 1363) | 3 |
| Terminal Output | Yes |
| TECHNICAL DETAILS |
| LINE Mode Efficiency [%] (Full Load) | 91.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 4ms |
| Load Crest Ratio | 3:1 |
| Additional Features | ECO Mode Available, CVCF Mode Available, REPO – Remote Emergent Power-Off, APFC – High Input PF, LCD Display, Battery Pack Available, Circuit Breaker Reset, Generator Compatible, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY |
| Batteries | 6x 12.0V/9.0Ah |
| DC Voltage | 6x 12.0V |
| Recharge Time | 4h to 90% |
| Full Load Backup Time [min] | 3.5 |
| Half Load Backup Time [min] | 13.5 |
| Charger | 1.5A |
| External Battery Pack | Yes |
| COMMUNICATION |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Software | PowerMaster |
| ENVIRONMENT |
| Noise Level | < 45dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 90% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS |
| Package Content | Input Power Cable, Manual, USB Cable, Warranty Card, UPS |
| Manual Languages | EN |
| EAN | 4260074982541 |
| Product Dimensions (DxWxH) [mm] | 416 x 196 x 342 mm |
| Product Weight [kg] | 25.4 |
| Package Dimensions (DxWxH) [mm] | 512 x 294 x 458 mm |
| Package Weight [kg] | 27.1 |
| Pcs. per Outer Carton | 1 |
