| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Tower |
| Power Capacity | 2000VA / 2000W |
| Output Power Factor | 1.00 |
| INPUT |
| Input Voltage Range | Line Low Transfer: 110-160VAC ± 5% depending on load level
Line Low Comeback: 125-175VAC ± 5% depending on load level
Line High Transfer: 300VAC ± 5%
Line High Comeback: 290VAC ± 5VAC |
| Max THDi | ≤ 5% @ 205-245VAC; THDu ≤ 1.6% @ input and full linear load condition |
| Frequency Range | 40Hz – 70Hz |
| Frequency (Synchronized Range) | 47Hz – 53Hz or 57Hz – 63Hz |
| OUTPUT |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 200/208/220/230/240 VAC |
| THDv | ≤2% @ 100% linear load, ≤4% @100% non-linear load |
| Voltage Regulation (Battery Mode) | ±1% |
| Frequency (Battery Mode) | ±0.1Hz |
| INPUT & OUTPUT CONNECTORS |
| Input Connector | C20 |
| Output Type | IEC |
| IEC C13 | 8 |
| TECHNICAL DETAILS |
| LINE Mode Efficiency [%] (Full Load) | 91.0 |
| Battery Mode Efficiency [%] (Full Load) | 90.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | 10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | 10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 4ms |
| Load Crest Ratio | 3:1 |
| Data Line Protection | RJ-11 Port, RJ-45 Port (100mbit) |
| Additional Features | ECO Mode Available, CVCF Mode Available, Potential Equalization Screw, LCD Display, Unity Power Factor 1.0, Battery Pack Available, Generator Compatible, EPO – Emergency Power Off, Programmable Segment Available, HID – Human Interface Device, AVR – Automatic Voltage Regulator |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY |
| Batteries | 6x 12.0V/7.0Ah |
| DC Voltage | 6x 12.0V |
| Recharge Time | 3h to 90% |
| Full Load Backup Time [min] | 4.4 |
| Half Load Backup Time [min] | 12.8 |
| Charger | 1A, 2A, 4A, 6A, 8A, [2A] |
| External Battery Pack | Yes |
| COMMUNICATION |
| Communication | USB Type B – for Monitoring Software, RS-232, Management Card Slot |
| Software | ViewPower |
| ENVIRONMENT |
| Noise Level | < 50dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 95% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS |
| Package Content | Input Power Cable, Manual, 2x IEC Cable, USB Cable, UPS |
| Manual Languages | DE, RU, PL, EN |
| EAN | 4260074979930 |
| Product Dimensions (DxWxH) [mm] | 421 x 190 x 318 mm |
| Product Weight [kg] | 23.2 |
| Package Dimensions (DxWxH) [mm] | 560 x 320 x 460 mm |
| Package Weight [kg] | 26.0 |
