| Type | Online Single Phase (VFI) |
| Phases (IN-OUT) | 1-1 |
| Form Factor | Rack, Tower |
| Rack Units [U] | 5U |
| Power Capacity | 10000VA / 10000W |
| Output Power Factor | 1.00 |
| INPUT |
| Input Voltage Range | 110-300 VAC @ 0-60% load
140-300 VAC @ 60-80% load
176-300 VAC @ 80-100% load |
| Max THDi | ≤4% @ 100% load; ≤6% @ 50% load |
| Frequency Range | 46Hz – 54Hz or 56Hz – 64Hz |
| Frequency (Synchronized Range) | 46Hz – 54Hz or 56Hz – 64Hz |
| OUTPUT |
| Waveform | Pure Sine Wave |
| Nominal Output Voltage | 208/220/230/240 VAC |
| THDv | ≤1.5% @ 100% linear load, ≤7% 100% non-linear load |
| Voltage Regulation (Battery Mode) | ±1% |
| Frequency (Battery Mode) | ±0.1Hz |
| INPUT & OUTPUT CONNECTORS |
| Input Connector | Terminal |
| Output Type | Terminal |
| Terminal Output | Yes |
| TECHNICAL DETAILS |
| LINE Mode Efficiency [%] (Full Load) | 94.0 |
| Battery Mode Efficiency [%] (Full Load) | 91.0 |
| Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms] | <10ms |
| Transfer Time (AC / Line Mode to Battery Mode) [ms] | 0ms |
| Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms] | <10ms |
| Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms] | 0ms |
| Load Crest Ratio | 3:1 |
| Bypass | Manual – Bypass |
| Additional Features | ECO Mode Available, Parallel Connectivity, LCD Display, Unity Power Factor 1.0, Input Breaker, Battery Pack Available, Generator Compatible, EPO – Emergency Power Off, HID – Human Interface Device |
| IEC 62040-3 classification | VFI-SS-111 |
| BATTERIES AND AUTONOMY |
| Batteries | 20x 12.0V/9.0Ah |
| DC Voltage | 20x 12.0V |
| Recharge Time | 3h to 90% |
| Full Load Backup Time [min] | 2.8 |
| Half Load Backup Time [min] | 8.4 |
| Charger | 1-6A [2A] |
| External Battery Pack | Yes |
| COMMUNICATION |
| Communication | Dry contact, RS-232, Management Card Slot |
| Software | ViewPower |
| Parallel Operation [Units] | 3 |
| ENVIRONMENT |
| Noise Level | < 58dB |
| Fan Logic | Always on, Automatic Speed Control |
| Temperature | 0°C – 40°C |
| Humidity | 20% – 95% RH (non-condensing) |
| IP | IP 20 |
| LOGISTICS |
| Package Content | Bundle (Please see additional packaging information) |
| Manual Languages | EN |
| EAN | 4260074981995 |
| Product Dimensions (DxWxH) [mm] | 600 x 438 x 220 mm |
| Product Weight [kg] | 90.0 |
| Package Weight [kg] | 93.8 |
| Addtional Packaging Information | This product is aBundle Product.For theindividual packaging information please look at the followingArticle Number:10122177(UPS Engine) +10120532(BP). |
| Pcs. per Outer Carton | 1 |
