MPL VRLA AGM 12V/5Ah Battery MWS 5-12 (90/70/101mm)

Manufacturer: Mpl
The MPL MWS 5-12 is a maintenance-free VRLA AGM rechargeable battery designed for standby and backup power applications such as UPS systems, alarms, emergency lighting, and automation equipment. It offers reliable 12V output in a compact sealed design.
SKU: MBT0047
Manufacturer part number: MWS 5-12
Availability: 60 in stock
€19.70 incl VAT
i h
  • Model: MWS 5-12
  • Battery Type: VRLA AGM (Valve Regulated Lead Acid)
  • Nominal Voltage: 12V
  • Capacity: 5Ah
  • Dimensions (L × W × H): 90 × 70 × 101 mm
  • Height with terminals: ~107 mm
  • Terminal Type: Faston 187 (T1)
  • Maximum Charge Current: 1.5 A
  • Maximum Discharge Current: 50 A
  • Standby: 13.5 – 13.8 V
  • Cyclic: 14.4 – 15.0 V
  • Operating Temperature: -20°C to 50°C
  • Internal Resistance: ~35 mΩ
  • Weight: ~1.4 kg
  • Design Life: 3–5 years
  • Technology: Sealed maintenance-free AGM
  • Applications: UPS, alarm systems, emergency lighting, automation, backup power
