Delock 86040 Bidirectional USB Type-C to Display Port Cable 8K 60 Hz 1.5 m DP 8K certified

Manufacturer: Delock

This DP 8K certified USB-C™ to DisplayPort cable by Delock enables the connection between different devices with USB Type-C™ and DisplayPort connectors. Versatile applications The bidirectional cable works in both signal directions and therefore offers a variety of possible applications. It can be used, for example, to connect a monitor or TV with DisplayPort socket to a laptop or smartphone with USB Type-C™ port. Alternatively it is possible to connect a USB Type-C™ monitor to a device with DisplayPort output. 8K Ultra HD resolution and HDR support By supporting a maximum bandwidth of 32.4 Gbps, content up to 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution can be displayed. Due to the HDR support colours are realistically displayed with impressive depth, brightness and contrast are optimally reproduced.

SKU: AUS0058

Manufacturer part number: 86040

Availability: 7 in stock

€53.40 incl VAT

Qty:

i h

Specification
Connectors:
1 x USB Type-C™ male >
1 x DisplayPort male
Chipset: Chrontel CH7213
DisplayPort 1.4 specification
Downwards compatible to DisplayPort 1.3, 1.2 and 1.1
DisplayPort® DP 8K certified cable
Cable gauge: 32 AWG
Cable diameter: ca. 4.8 mm
Copper conductor
Triple shielded cable
Contacts gold-plated
Transmission of audio and video signals
Data transfer rate up to 32.4 Gbps
Resolution up to:
Display with DSC support:
7680 x 4320 @ 60 Hz
5120 x 2880 @ 120 Hz
3840 x 2160 @ 240 Hz
Display without DSC support:
7680 x 4320 @ 30 Hz
5120 x 2880 @ 60 Hz
3840 x 2160 @ 120 Hz
(depending on the system and the connected hardware)
Supports Display Stream Compression 1.2 (DSC)
Supports HDR
Supports HDCP 1.4 and 2.2
Supports HBR3 (8.1 Gbps) data rate
Up to 32 audio channels for speakers
Up to 1536 kHz audio sampling rate
Supports colour sampling in 4:4:4, 4:2:2 and 4:2:0 format
Plug & Play
Colour: black
Length incl. connectors: ca. 1.5 m

System requirements
Android 8.0 or above
Chrome OS 71.0 or above
iOS 12.1.4 or above
Mac OS 10.14.2 or above
Windows 7/7-64/8.1/8.1-64/10/10-64
PC or laptop with a free USB Type-C™ port and DisplayPort alternate mode or
PC or laptop with a free Thunderbolt™ 3 port
A free DisplayPort interface

Package content
USB-C™ to DisplayPort cable

Package
Retail Box
